Muse Series

EZ LED Muse series is a cutting-edge display solution designed to adapt to your creative vision. What sets Muse apart is its unparalleled flexibility. Crafted with bendable rubber modules, it effortlessly shapes into concave, convex, or even wave-like forms, enabling dynamic and unique designs that transform any space.


Ultimate Creativity

Soft and bendable rubber modules for ultimate flexibility (concave, convex, wave-shape, or any shape)

Ultra High Definition

Super fine pixel pitch like 0.9mm, 1.2mm available, easy to build 4K or higher-res curve LED walls.

Supported By EZ Engineering

Project-based custom made LED wall frame design strongly supported by EZ LED's experienced engineering team to help you realize any wild/crazy idea of an LED display. Spheres and cylinders are just normal shapes we do.

Versatile Installation

All mounting solutions inculding wall mounting, ceiling hanging, and floor standing compatible. Rich mounting accessories available for all sorts of needs.


User Friendly

Full front access servicability greatly simplfies the install and maintenance works.


Specifications
Muse 0.9mm
Muse 1.2mm
Muse 1.5mm
Muse 1.6mm
Muse 1.8mm
Muse 2.0mm
Muse 2.5mm
Muse 3.0mm
Muse 4.0mm
Muse 3.0mm (outdoor)
Muse 4.0mm (outdoor)
Product Model
Per Module Resolution
Module Size (W*H)
Module Depth
Brightness
Refresh Rate
Grayscale
Contrast Ratio
View Angle
Maximum Module Curve (MMC)*
Minimum Bending Diameter (MBD)*
Service Access
Per Module Weight
Per Module Power Consumption (max)
Per Module Power Consumption (typical)
Color Gamut
Color Temperature
Service Life
Working Voltage
Operating Temperature

Muse 0.9mm

256*128

240x120mm / 9.48''x4.74''

8.4mm/0.33''

500 nits

2880-3840 HZ

13-14 bit

6000 :  1

160° Horizontal / 160° Vertical

22°

1222mm /48.1''

Front Service / Rear Service

220G / 0.484 LBS

14W

4W

100% NTSC

3,000-10,000 K

100,000 Hours

100V-240V Auto-switching

-20°to 40°C  / -4° to 104°F

(20-75% relative humidity, non-condensing)

Muse 1.2mm

192*96

240x120mm / 9.48''x4.74''

8.6mm/0.34''

600 nits

3840 HZ

13-14 bit

6000 :  1

160° Horizontal / 160° Vertical

22°

1222mm /48.1''

Front Service / Rear Service

220G / 0.484 LBS

16W

5W

100% NTSC

3,000-10,000 K

100,000 Hours

100V-240V Auto-switching

-20°to 40°C  / -4° to 104°F

(20-75% relative humidity, non-condensing)

Muse 1.5mm

152*76

240x120mm / 9.48''x4.74''

8.6mm/0.34''

600 nits

3840 HZ

13-14 bit

6000 :  1

160° Horizontal / 160° Vertical

30°

917mm/36.1''

Front Service / Rear Service

220G / 0.484 LBS

16W

5W

100% NTSC

3,000-10,000 K

100,000 Hours

100V-240V Auto-switching

-20°to 40°C  / -4° to 104°F

(20-75% relative humidity, non-condensing)

Muse 1.6mm

144*72

240x120mm / 9.48''x4.74''

8.6mm/0.34''

600 nits

3840 HZ

13-14 bit

6000 :  1

160° Horizontal / 160° Vertical

36°

764mm/30''

Front Service / Rear Service

200G / 0.44 LBS

16W

5W

100% NTSC

3,000-10,000 K

100,000 Hours

100V-240V Auto-switching

-20°to 40°C  / -4° to 104°F

(20-75% relative humidity, non-condensing)

Muse 1.8mm

128*64

240x120mm / 9.48''x4.74''

8.6mm/0.34''

700 nits

3840 HZ

13-14 bit

5000 :  1

160° Horizontal / 160° Vertical

44°

611mm/24.1''

Front Service / Rear Service

220G / 0.484 LBS

16W

5W

100% NTSC

3,000-10,000 K

100,000 Hours

100V-240V Auto-switching

-20°to 40°C  / -4° to 104°F

(20-75% relative humidity, non-condensing)

Muse 2.0mm

120*60

240x120mm / 9.48''x4.74''

8.6mm/0.34''

700 nits

3840 HZ

13-14 bit

5000 :  1

160° Horizontal / 160° Vertical

44°

611mm/24.1''

Front Service / Rear Service

210G / 0.462 LBS

16W

5W

100% NTSC

3,000-10,000 K

100,000 Hours

100V-240V Auto-switching

-20°to 40°C  / -4° to 104°F

(20-75% relative humidity, non-condensing)

Muse 2.5mm

96*48

240x120mm / 9.48''x4.74''

8.6mm/0.34''

700 nits

1920-3840 HZ

13-14 bit

5000 :  1

160° Horizontal / 160° Vertical

90°

306mm/12.1''

Front Service / Rear Service

190G / 0.418 LBS

14W

4W

100% NTSC

3,000-10,000 K

100,000 Hours

100V-240V Auto-switching

-20°to 40°C  / -4° to 104°F

(20-75% relative humidity, non-condensing)

Muse 3.0mm

80*40

240x120mm / 9.48''x4.74''

8.6mm/0.34''

800 nits

1920 HZ

13-14 bit

5000 :  1

160° Horizontal / 160° Vertical

90°

306mm/12.1''

Front Service / Rear Service

190G / 0.418 LBS

14W

4W

100% NTSC

3,000-10,000 K

100,000 Hours

100V-240V Auto-switching

-20°to 40°C  / -4° to 104°F

(20-75% relative humidity, non-condensing)

Muse 4.0mm

60*30

240x120mm / 9.48''x4.74''

8.6mm/0.34''

800 nits

1920 HZ

13-14 bit

5000 :  1

160° Horizontal / 160° Vertical

90°

306mm/12.1''

Front Service / Rear Service

175G / 0.385 LBS

14W

4W

100% NTSC

3,000-10,000 K

100,000 Hours

100V-240V Auto-switching

-20°to 40°C  / -4° to 104°F

(20-75% relative humidity, non-condensing)

Muse 3.0mm (outdoor)

104*52

320x160mm / 12.6''x6.3''

12mm/0.47''

5000 nits

3840 HZ

12 bit

3000 :  1

160° Horizontal / 160° Vertical

36°

1019mm /40.1''

Front Service

610G / 1.34 LBS

31W

9W

100% NTSC

3,000-10,000 K

100,000 Hours

100V-240V Auto-switching

-20°to 50°C  / -4°to 122°F

(20-90% relative humidity, non-condensing)

Muse 4.0mm (outdoor)

80*40

320x160mm / 12.6''x6.3''

12mm/0.47''

5000 nits

3840 HZ

12 bit

3000 :  1

160° Horizontal / 160° Vertical

36°

1019mm /40.1''

Front Service

610G / 1.34 LBS

31W

9W

100% NTSC

3,000-10,000 K

100,000 Hours

100V-240V Auto-switching

-20°to 50°C  / -4°to 122°F

(20-90% relative humidity, non-condensing)
